H1242SC

Home Product Introduction H. Back Buttons / Hinges H1242SC
  • H1242SC-1
  • ALL_catalog_25J31_4SNRSlE7pq
  • ALL_catalog_25J31_nLCciBIWdE
  • ALL_catalog_25J31_XDr3sA3Oc2
  • H1242SC-1
  • ALL_catalog_25J31_4SNRSlE7pq
  • ALL_catalog_25J31_nLCciBIWdE
  • ALL_catalog_25J31_XDr3sA3Oc2
H1242SC-1 ALL_catalog_25J31_4SNRSlE7pq ALL_catalog_25J31_nLCciBIWdE ALL_catalog_25J31_XDr3sA3Oc2
Product Name H1242SC 304 Stainless Steel Soft-Close Hinge Series
Cup Diameter φ35 mm
Material 304 Stainless Steel (including stainless steel mounting screws)
Base Type 4-hole base, available in Airplane Plate and Square Plate versions
Mounting Type Clip-on / Detachable design for easy installation and removal
Function Built-in soft-close hydraulic damper for silent closing
Opening Type Straight Arm (Full Overlay) / Half Overlay / Inset (Large Bend)
Finish Natural Stainless Finish
Product Name H1242SC 304 Stainless Steel Soft-Close Hinge Series
Cup Diameter φ35 mm
Material 304 Stainless Steel (including stainless steel mounting screws)
Base Type 4-hole base, available in Airplane Plate and Square Plate versions
Mounting Type Clip-on / Detachable design for easy installation and removal
Function Built-in soft-close hydraulic damper for silent closing
Opening Type Straight Arm (Full Overlay) / Half Overlay / Inset (Large Bend)
Finish Natural Stainless Finish



Model Description Specifications & Features
φ35 Soft-Close Hinge | 4-Hole Base | Airplane Plate | Clip-On | Full Overlay Made of 304 stainless steel with stainless screws. Suitable for full-overlay doors with smooth and silent closing.
φ35 Soft-Close Hinge | 4-Hole Base | Airplane Plate | Clip-On | Half Overlay Durable stainless steel structure. Ideal for shared frame cabinets, ensuring quiet and cushioned closing motion.
φ35 Soft-Close Hinge | 4-Hole Base | Airplane Plate | Clip-On | Inset Type High corrosion resistance for inset doors, ensuring smooth motion and long service life in humid environments.





  • ALL_catalog_25J31_4SNRSlE7pq

  • ALL_catalog_25J31_XDr3sA3Oc2

  • ALL_catalog_25J31_nLCciBIWdE

Applications Recommended Environments
Kitchen cabinets, medical equipment, outdoor furniture, laboratory drawers 304 stainless steel material offers excellent anti-rust performance in humid or oily environments.
Indoor furniture, display cabinets, industrial enclosures Soft-close function improves lifespan and ensures smooth operation for frequent use.
Disclaimer

All technical data, dimensions, and product descriptions are provided for reference only. Actual performance may vary depending on installation method, door thickness, humidity level, and usage frequency.

Yeachiuan Industrial Co., Ltd. strives to maintain product accuracy and consistency but does not guarantee that all information is current or applicable for all environments. Product design, structure, or packaging may change without prior notice as part of continuous improvement.

Installation should be performed by qualified personnel to ensure proper alignment and stability. Yeachiuan Industrial is not responsible for any damages or malfunctions caused by improper installation, overloading, corrosion, or modification of product structure.

All product photos and specifications are for illustration purposes only. Actual delivered products may vary slightly. Yeachiuan Industrial reserves the right to interpret and update product and technical content without notice.

Last Updated: October 2025
